CNC VARIABLE RAKE ANGE HYDRAULIC GUILLOTINE SHEARS- MVD C Series

VARIABLE RAKE ANGEL HYDRAULIC GUILLOTTINE SHEARS C SERIES

C Series Hydraulic Variable Rake Angle Shears automatic cutting angle calculating, provides high cutting quality in the widest range of materials type and sheet thickness. Automatically calculates and apply; cutting angle, blade gap adjustment, stroke of the cutting length, back gauge positioning according to material type and thickness with CNC controller and servo hydraulic valve.

Standard Features

• ELGO P40T Touch screen NC Control Unit
• Rexroth / Hoerbiger hydraulic system
• CNC controlled Auto blade gap, stroke and blade ad- justment system
• mm NC Controlled, Programmable, motorized back gauge
• 250 mm throat depth
• Programmable back gauge retract feature
• Back gauge swing-up feature for sheets longer than 1.000 mm
• Stroke adjustment on the control panel to increase stroke/min during cutting short parts
• Transfer table with roller balls
• Upper blade 2 edges / Bottom blade 4 edges
• Components that reduce maintenance need.
• Front support arms 1.000 mm, with ruler scale, T channel & flip stops
• Front and side protective covers
• Illumination cutting line
• Front finger protection guard, 1.000mm which has swing-up feature
• Foot pedal
• Special designed covers with movable controller arm
• Emergency stop buttons

Optional Features

• Pneumatic Sheet support system (Type 1)
• Pneumatic Sheet support system- with Return to sender feature (Type 2)
• Angular gauge 0-180º
• Longer front sheet supports & squaring arm
• Special throat depth 500 mm
• Full length opening front finger guard
• Laser guard for front finger protection
• Special alloy blades
• Laser cutting line
• Oil cooler and oil heater
• Automatic or Manual central lubrication
• AC cooling unit electrical cabinet
• CNC controlled front sheet feeder arms
• Rear laser barrier with CE conformity
• Machine without special design covers
