MICROCUT HORIZONTAL TURNING MACHINE SERIES BNC-2200

The double box way flat-bed lathe, BNC-2200 provides advanced features such as high spindle speed, fast rapid feed assures short processing time. Machine can be operated as a full CNC machine or by using conversational programming as well as a manual machine. The user-friendly teaching function enables the operator to learn easily within a short period of time.

Features

The double box-way design is used for rapid traverse in extremely wide bed to carry heavy workpieces.

Ballscrew support bracket for bed length longer than 3 meters to ensure accuracy

Equipped with a pneumatic automatic spindle speed changer, enabling the machine running under full automatic mode.

Swing in gap	770 mm
Swing over bed	550 mm
Swing over cross slide	310 mm
Max. cutting length (with turret)	1000/1500/2000/3000/4000 mm
X axis travel	345 mm
Y axis travel(Option)	±40 mm
Z axis travel	1150/1650/2150/3150/4150 mm
Rapid feed(X /Y/ Z)	X: 15/ Y: 7.5/ Z: 15 (tavel< 2m) / 12 (travel 3m & 4m) m/min
Spindle bore	82 (std.) / 106 (opt.) mm
Spindle speed	Fagor / Siemens: 0-3500 (82mm bore); 0-2400 (82mm bore); 0-2400 (106mm bore) rpm Fanuc: 0-3500 (82mm bore); 0-2100 (82mm bore); 0-2100 (106mm bore) rpm
Spindle motor	Fagor: 11/15.5 kw Fanuc: 11/15, and 15/18.5 kw Siemens: 12/18(std.),15/22.5(opt.) kw
Machine weight	3800/4300/4800/5800/6800 kg

Swing in gap

770 mm

Swing over bed

550 mm

Swing over cross slide

310 mm

Max. cutting length (with turret)

1000/1500/2000/3000/4000 mm

X axis travel

345 mm

Y axis travel(Option)

±40 mm

Z axis travel

1150/1650/2150/3150/4150 mm

Rapid feed(X /Y/ Z)

X: 15/ Y: 7.5/ Z: 15 (tavel< 2m) / 12 (travel 3m & 4m) m/min

Spindle bore

82 (std.) / 106 (opt.) mm

Spindle speed

Fagor / Siemens:
0-3500 (82mm bore); 0-2400 (82mm bore); 0-2400 (106mm bore) rpm
Fanuc:
0-3500 (82mm bore); 0-2100 (82mm bore); 0-2100 (106mm bore) rpm

Spindle motor

Fagor: 11/15.5 kw
Fanuc: 11/15, and 15/18.5 kw
Siemens: 12/18(std.),15/22.5(opt.) kw

Machine weight

3800/4300/4800/5800/6800 kg
