      Boroscop industrial multi-prismatic

      Rugged, high-resolution optics
      Sondendrehung 370°
      Probe rotation: 370° circumferential scanning capbility
      Direction 7° to 133°
      Field of View: 45°
      Variable working lengths
      6,8 and 9 mm probe diameters
      Custom designs available

      Technical Data



      Ø 6,0mm

      LengthDoVFoVRotatableConstruction
      175mm-7° to 133°45°yes, 370°Stainless Steel
      245mm-7° to 133°45°yes, 370°Stainless Steel
      315mm-7° to 133°45°yes, 370°Stainless Steel
      385mm-7° to 133°45°yes, 370°Stainless Steel
      455mm-7° to 133°45°yes, 370°Stainless Steel
      945mm-7° to 133°45°yes, 370°Stainless Steel



      Ø 8,0mm

      LengthDoVFoVRotatableConstruction
      115mm-7° to 133°45°yes, 370°Stainless Steel
      185mm-7° to 133°45°yes, 370°Stainless Steel
      255mm-7° to 133°45°yes, 370°Stainless Steel
      325mm-7° to 133°45°yes, 370°Stainless Steel
      395mm-7° to 133°45°yes, 370°Stainless Steel
      465mm-7° to 133°45°yes, 370°Stainless Steel
      605mm-7° to 133°45°yes, 370°Stainless Steel



      Ø 9,0mm

      LengthDoVFoVRotatableConstruction
      205mm-7° to 133°45°yes, 370°Stainless Steel
      305mm-7° to 133°45°yes, 370°Stainless Steel
      405mm-7° to 133°45°yes, 370°Stainless Steel
      505mm-7° to 133°45°yes, 370°Stainless Steel
      605mm-7° to 133°45°yes, 370°Stainless Steel
      705mm-7° to 133°45°yes, 370°Stainless Steel

      Описание

      Rugged, high-resolution optics
      Sondendrehung 370°
      Probe rotation: 370° circumferential scanning capbility
      Direction 7° to 133°
      Field of View: 45°
      Variable working lengths
      6,8 and 9 mm probe diameters
      Custom designs available

      Technical Data



      Ø 6,0mm

      LengthDoVFoVRotatableConstruction
      175mm-7° to 133°45°yes, 370°Stainless Steel
      245mm-7° to 133°45°yes, 370°Stainless Steel
      315mm-7° to 133°45°yes, 370°Stainless Steel
      385mm-7° to 133°45°yes, 370°Stainless Steel
      455mm-7° to 133°45°yes, 370°Stainless Steel
      945mm-7° to 133°45°yes, 370°Stainless Steel



      Ø 8,0mm

      LengthDoVFoVRotatableConstruction
      115mm-7° to 133°45°yes, 370°Stainless Steel
      185mm-7° to 133°45°yes, 370°Stainless Steel
      255mm-7° to 133°45°yes, 370°Stainless Steel
      325mm-7° to 133°45°yes, 370°Stainless Steel
      395mm-7° to 133°45°yes, 370°Stainless Steel
      465mm-7° to 133°45°yes, 370°Stainless Steel
      605mm-7° to 133°45°yes, 370°Stainless Steel



      Ø 9,0mm

      LengthDoVFoVRotatableConstruction
      205mm-7° to 133°45°yes, 370°Stainless Steel
      305mm-7° to 133°45°yes, 370°Stainless Steel
      405mm-7° to 133°45°yes, 370°Stainless Steel
      505mm-7° to 133°45°yes, 370°Stainless Steel
      605mm-7° to 133°45°yes, 370°Stainless Steel
      705mm-7° to 133°45°yes, 370°Stainless Steel
