Centru de prelucrare vertical 5 axe - Trimill VS1614
5-AXIS WITH TILTING ROTARY TABLE
- Rigid 5-axis machine designed for accurate single-piece production
- Upper gantry portal machine for high dynamics and accuracy
- Unique closed design of the cross-beam and cross-slide (box-in-box design) with internal, quadruple-guided, ram-type milling unit
- Constantly perfect cutting results thanks to unique thermo-symmetric design
- Workpiece positioned on tilting rotary table
- Quick setup and commissioning of the machine – machine is transported fully assembled
- Ergonomic configuration – easy access to the machine tool interior
- High productivity – roughing and finishing operations in one set-up
- Superior cost-performance ratio
- Tilting rotary table with 1 200 mm diameter equipped with torque motors
- Load up to 2 500 kg
- Stainless steel internal covers of the machine
- Direct measuring in all axis
- Vibration sensing system
- Quick setup and commissioning of the machine – machine is transported fully assembled
Technical data
| Travels | |
|---|---|
| X-axis [mm] | 1.600 |
| Y-axis [mm] | 1.400 |
| Z-axis [mm] | 800 |
| Optional spindle / head | |
| Power (S1/100%) [kW] | 25 |
| Torque (S1/100%) [Nm] | 200 |
| Speed [rpm] | 12.000 |
| Tool adoption | HSK – A 100 |
| Swivel axis [°] | -130/+130 |
| Rotary axis [°] | n x 360 |
| Clamping torque (swivel axis) [Nm] | 10.000 |
| Clamping torque (rotary axis) [Nm] | 6.500 |
| Optional spindle / head | |
| Power (S1/100%) [kW] | 32 |
| Torque (S1/100%) [Nm] | 306 |
| Speed [rpm] | 14.000 |
| Tool holder | HSK – A 100 |
| Optional spindle / head | |
| Power (S1/100%) [kW] | 29 |
| Torque (S1/100%) [Nm] | 69 |
| Speed [rpm] | 24.000 |
| Tool holder | HSK – A 63 |
| Clamping surface [mm] | Ø 1.200 mm |
| Workpiece weight [kg] | 2.500 kg |
| Feed rate [mm/min] | 30.000 |
| Acceleration [m/s2] | 3 |
| Weight of machine [kg] |
