      Masina de alezat si frezat T type Microcut HBM-5TL

      Enlarged HBM-5TL travelling column boring and milling center with increased travel on X/Y/Z axes up to 5500mm/3200mm/2000mm and a bigger working table 2500x2500mm with a heavy loading capacity of 20000kgs. Dia. 130mm spindle driven by a powerful gear box offers both high power and torque. The machine can be equipped with a wide selection of technological accessories that significantly increases the usability of the unit. Either Fanuc, Heidenhain or Siemens controls can be selected.

      Specification:

      ITEM UNIT HBM-5TL
       X axis table cross travel mm 4500 (std); 5500 (opt)
       Y axis headstock vertical mm 3200
       Z axis table long travel mm 200
       Quill diameter mm 130
       W axis (quill) travel mm 700
       Spindle power kW 37/45 (std)
       Max. spindle speed rpm 35-3000
       Spindle torque Nm 1942/2362 (std)
       Spindle gear range   2 step (1:1 / 1:5.5)
       Table size mm 2500 x 2500
       Rotary table indexing degree degree 0.001°
       Table rotation speed rpm 1.5
       Max. table loading capacity kg 20000
       Rapid feed (X/Y/Z/W) m/min 10/10/10/8
       ATC tool number   60
       Machine weight kg

      55000;58000(opt)

      Standard accessories:

      • Spindle and servo motor package
      • Precision ground ball screw
      • Heavily ribbed cast iron components
      • Heavy duty radius type metal enclosure with removable slide
      • Automatic central lubrication
      • Coolant system
      • Chip drawers
      • Telescopic way covers
      • 3000rpm spindle
      • Low voltage circuit system
      • User operation station
      • Oil skimmer
      • Heat exchanger

      Optional accessories:

      • Universal head
      • Right angle milling head
      • Spindle extension sleeve
      • Coolant Through Spindle Device
      • Table guard for CTS function
      • Air conditioner for electric cabinet
      • Safety module
      • Lifting device

      Описание

      Enlarged HBM-5TL travelling column boring and milling center with increased travel on X/Y/Z axes up to 5500mm/3200mm/2000mm and a bigger working table 2500x2500mm with a heavy loading capacity of 20000kgs. Dia. 130mm spindle driven by a powerful gear box offers both high power and torque. The machine can be equipped with a wide selection of technological accessories that significantly increases the usability of the unit. Either Fanuc, Heidenhain or Siemens controls can be selected.

      Specification:

      ITEM UNIT HBM-5TL
       X axis table cross travel mm 4500 (std); 5500 (opt)
       Y axis headstock vertical mm 3200
       Z axis table long travel mm 200
       Quill diameter mm 130
       W axis (quill) travel mm 700
       Spindle power kW 37/45 (std)
       Max. spindle speed rpm 35-3000
       Spindle torque Nm 1942/2362 (std)
       Spindle gear range   2 step (1:1 / 1:5.5)
       Table size mm 2500 x 2500
       Rotary table indexing degree degree 0.001°
       Table rotation speed rpm 1.5
       Max. table loading capacity kg 20000
       Rapid feed (X/Y/Z/W) m/min 10/10/10/8
       ATC tool number   60
       Machine weight kg

      55000;58000(opt)

      Standard accessories:

      • Spindle and servo motor package
      • Precision ground ball screw
      • Heavily ribbed cast iron components
      • Heavy duty radius type metal enclosure with removable slide
      • Automatic central lubrication
      • Coolant system
      • Chip drawers
      • Telescopic way covers
      • 3000rpm spindle
      • Low voltage circuit system
      • User operation station
      • Oil skimmer
      • Heat exchanger

      Optional accessories:

      • Universal head
      • Right angle milling head
      • Spindle extension sleeve
      • Coolant Through Spindle Device
      • Table guard for CTS function
      • Air conditioner for electric cabinet
      • Safety module
      • Lifting device
