Sistem de marcare cu laser Lasit TowerComfort

Product Description

The TowerComfort laser marking machine is extremely versatile and configurable in order to meet a wide range of needs, and it allows the operator to work comfortably sit.

The laser engraver offers a lot of working space given the amount of space the machine actually takes up and still acts as a stand-alone unit, with the opportunity to add various accessories.

It can be equipped with different types of laser sources; the X and Z axes can be fully controlled via the FlyCAD marking software. The motors, which feature an integrated encoder, can also be controlled via a joystick to immediately focus in with SmartFocus technology.

Additional Information

Working position	Seated
Working plane dimensions	620 x 450
Max weight on the plane	100Kg
Markable max height (ø 140mm)	450mm
Available marking areas
Options which can be installed	Rotaing axis, direct rotating axis, tilting rotating axis, metal sheet tightener
Type of laser	FiberFly, FlyAIR, FlyAir Green, FiberFly Green, FlyCO2
Vision system	Optional – both TTL and Reflex
Type of engine	Up to 4 motors with encoder
Joystick	Included
Type of door	Manual or pneumatic
Exhaust fan and filter	Integrated into the base – optional
Pc and monitor	Integrated into the base and monitor holder
DMX player	Optional
Weight	235Kg
Power supply	110 – 230 Vac – 50Hz

Product Description

The TowerComfort laser marking machine is extremely versatile and configurable in order to meet a wide range of needs, and it allows the operator to work comfortably sit.

The laser engraver offers a lot of working space given the amount of space the machine actually takes up and still acts as a stand-alone unit, with the opportunity to add various accessories.

Additional Information

Working position

Seated

Working plane dimensions

620 x 450

Max weight on the plane

100Kg

Markable max height (ø 140mm)

450mm

Available marking areas

Options which can be installed

Rotaing axis, direct rotating axis, tilting rotating axis, metal sheet tightener

Type of laser

FiberFly, FlyAIR, FlyAir Green, FiberFly Green, FlyCO2

Vision system

Optional – both TTL and Reflex

Type of engine

Up to 4 motors with encoder

Joystick

Included

Type of door

Manual or pneumatic

Exhaust fan and filter

Integrated into the base – optional

Pc and monitor

Integrated into the base and monitor holder

DMX player

Optional

Weight

235Kg

Power supply

110 – 230 Vac – 50Hz
