      Makino L2 APC Vertical Machining Centers

      L2 APC High Performance Machining Center

      The L2 vertical machining center is designed for high-volume, small-part manufacturing. Combining rigid construction, a compact footprint and flexible spindle design, the L2 offers a highly stable and reliable machine platform for fully unattended, around-the-clock part processing.  Given the small size of the machine, it can be effectively employed in virtually any type of workpiece flow arrangement – ranging from manual part transfers to automated part movement facilitated by robotic systems.  The L2 can be deployed to meet the specific needs of any manufacturing environment.

      Table Size300mm diameter
      X400mm
      Y300mm
      Z300mm
      Spindle RPM16,000 (HSK-A50), Optional – 8,000 (HSK-A50)
      Rapid Traverse48 m/min
      Cutting Feedrate48 m/min
      Maximum Workpiece413 x 267 x 215 mm
      Maximum Payload60 kg
      ATC Capacity30 (HSK-A50) – Standard
      Chip to Chip3.5 to 4.5 sec
      Maximum Tool Length250 mm (with limitation)
      Maximum Tool Diameter30mm / 80mm (ALL/ADJ)
      Maximum Tool Weight5 kg

      The L2 is a high performance oriented vertical machining center that provides the optimum solution for high-production, small component machining.  Equipped with a 16,000 RPM, 20 HP, HSK – A50 spindle, the machine can easily tackle the rigorous milling, drilling and tapping tasks required for various production parts  – and has the speed and acceleration to dramatically minimize part cycle times.  A 30 tool magazine insures a wide variety of tools to address any part configuration.

      Complete with a “built – in” pallet changer, the machine provides for fast, efficient part exchange – maximizing machine utilization and minimizing part floor – to – floor times.  The standard A – Axis rotary table also provides access to machine features of the part not normally accessible on a traditional vertical machining center.

      At only 3 feet wide x 7 feet deep, the machine minimizes the floor space required to achieve high levels of production, can be readily moved and reconfigured and is a breeze to integrate with various types of automation.

      Standard Features:

      • Stroke – up Specification
      • Thirty (30) Tool Magazine
      • 16,000 rpm, HSK–A50 Spindle
      • A – Axis Rotary Table with APC
      • Automatic Indexing Stocker
      • 400 L Coolant Tank
      • Rear discharge LUCC
      • X, Y, Z Axis Roller Guides
      • X, Y, Z Axis Scale Feedback (0.05 micron)
      • Broken Tool Sensor at ATC Side
      • Overhead Shower Coolant
      • 210psi Through Spindle Coolant
      • Nozzle Coolant
      • Right Discharge LUCC
      • Fixture Shower Coolant for Stocker
      • Splash and Chip Shield
      • Automatic Grease Supply Unit
      • Automatic Open / Close Front Door
      • Fixture Hydraulic & Air Supply
      • Air Dryer
      • Makino Professional L Control
      • Inch/Metric Selection
      • Helical Interpolation
      • Cylindrical Interpolation
      • Part Program Storage (1,280 m)
      • Part Programs (400 Total)
      • Tool Offsets (400 Total)
      • Work Coordinate Pairs (48)
      • High Speed Skip Function
      • Rigid Tapping
      • Fixed Type MPG
      • Custom Macro (700 variables)
      • Extended Part Program Editing
      • Run Hour and Parts Quantity Display
      • Worklight
      • Signal Light (3 layer)

      Description

      L2 APC High Performance Machining Center

      The L2 vertical machining center is designed for high-volume, small-part manufacturing. Combining rigid construction, a compact footprint and flexible spindle design, the L2 offers a highly stable and reliable machine platform for fully unattended, around-the-clock part processing.  Given the small size of the machine, it can be effectively employed in virtually any type of workpiece flow arrangement – ranging from manual part transfers to automated part movement facilitated by robotic systems.  The L2 can be deployed to meet the specific needs of any manufacturing environment.

      Table Size300mm diameter
      X400mm
      Y300mm
      Z300mm
      Spindle RPM16,000 (HSK-A50), Optional – 8,000 (HSK-A50)
      Rapid Traverse48 m/min
      Cutting Feedrate48 m/min
      Maximum Workpiece413 x 267 x 215 mm
      Maximum Payload60 kg
      ATC Capacity30 (HSK-A50) – Standard
      Chip to Chip3.5 to 4.5 sec
      Maximum Tool Length250 mm (with limitation)
      Maximum Tool Diameter30mm / 80mm (ALL/ADJ)
      Maximum Tool Weight5 kg

      The L2 is a high performance oriented vertical machining center that provides the optimum solution for high-production, small component machining.  Equipped with a 16,000 RPM, 20 HP, HSK – A50 spindle, the machine can easily tackle the rigorous milling, drilling and tapping tasks required for various production parts  – and has the speed and acceleration to dramatically minimize part cycle times.  A 30 tool magazine insures a wide variety of tools to address any part configuration.

      Complete with a “built – in” pallet changer, the machine provides for fast, efficient part exchange – maximizing machine utilization and minimizing part floor – to – floor times.  The standard A – Axis rotary table also provides access to machine features of the part not normally accessible on a traditional vertical machining center.

      At only 3 feet wide x 7 feet deep, the machine minimizes the floor space required to achieve high levels of production, can be readily moved and reconfigured and is a breeze to integrate with various types of automation.

      Standard Features:

      • Stroke – up Specification
      • Thirty (30) Tool Magazine
      • 16,000 rpm, HSK–A50 Spindle
      • A – Axis Rotary Table with APC
      • Automatic Indexing Stocker
      • 400 L Coolant Tank
      • Rear discharge LUCC
      • X, Y, Z Axis Roller Guides
      • X, Y, Z Axis Scale Feedback (0.05 micron)
      • Broken Tool Sensor at ATC Side
      • Overhead Shower Coolant
      • 210psi Through Spindle Coolant
      • Nozzle Coolant
      • Right Discharge LUCC
      • Fixture Shower Coolant for Stocker
      • Splash and Chip Shield
      • Automatic Grease Supply Unit
      • Automatic Open / Close Front Door
      • Fixture Hydraulic & Air Supply
      • Air Dryer
      • Makino Professional L Control
      • Inch/Metric Selection
      • Helical Interpolation
      • Cylindrical Interpolation
      • Part Program Storage (1,280 m)
      • Part Programs (400 Total)
      • Tool Offsets (400 Total)
      • Work Coordinate Pairs (48)
      • High Speed Skip Function
      • Rigid Tapping
      • Fixed Type MPG
      • Custom Macro (700 variables)
      • Extended Part Program Editing
      • Run Hour and Parts Quantity Display
      • Worklight
      • Signal Light (3 layer)
