TD SERIES Z800 – Z1359 –  HIGH PRECISION LATHE –CMZ

There is a machine for each type of machining.

Those looking for a highly accurate and reliable high precision lathe have a wide range of possibilities in the TD Z800-Z1350 Series.

This product range joins the smaller size lathes of the TA Series, offering a CNC lathe that allows multiple configuration options,

always adapted to the demands and particularities of each production process.

All models have a turret with a built-in motor offering 12,000 rpm driven tools, cooled with oil.

Machining times are reduced thanks to the integrated spindles.

Laser compensation is also a standard feature on all TD Z800-Z1350 Series machines.

The automation of both short and long batches is possible with the GL20 and GL100 Gantry robots, that will lift up to 100 kg.

Delve into the TD Z800-Z1350 Series and find the high precision lathe you are looking for.

CONFIGURE YOUR HIGH PRECISION LATHE

 TD-30-Y-Z800

TD-30-YS-Z800

TD-35-Y-Z1350

TD-45-Y-Z1350

TURRET WITH A BUILT-IN MOTOR

13 kW, 105 Nm, 12.000 rpm

This high precision lathe incorporates a robustly built oil-cooled turret whose large-diameter tool-holder disk reduces interference between tools and chuck.

There are two turret options: 12-position and 16-position disk with an indexing time is 30º in 200 ms.

MAXIMUM PRECISION AND TIME REDUCTION

INTEGRATED SPINDLES

The spindles of this high precision lathe are oil cooled.

They are also integrated, which means they do not have belts or pulleys, resulting in much less noise and a better surface finish.

All this increases accuracy and reduces machining time.
