NOVOTEST T-D3 Leeb Hardness Tester

The Leeb method of hardness testing of metals is the most popular because of its ease of use. The user does not need to have special skills and or knowledge in the field of hardness measurement, to perform the measurement, it is necessary to load the impact body of the probe of the device, install the probe on the tested surface, press the probe release button and the hardness value will be displayed on the device screen.

This method is recommended for large products, weighing 5 kg and more and 10 mm thick and more, but, subject to certain product mounting requirements, it is also possible to measure small parts.

Scales and materials – the machine comes with pre-calibrations for various scales and materials, making the machine universal.

• Scales: HRC, HRB, HB, HV, HL, MPa.
• Materiales: steel, alloy steel, cast iron, stainless steel, aluminium, bronze, brass, copper.

Low surface quality and material structure requirements

The Leeb NOVOTEST T-D3 hardness tester can be used for products with a poorly prepared surface (roughness of 3.2 Ra and more) as well as for materials with a coarse-grained structure, such as cast iron and others.

Advantages

• Large, colour graphic display with bright backlighting
• Various measurement modes: statistical, graphical, histogram, smart, signal
• Calibration of any scale in any range
• Convenience and ease of measurement
• Optimised number of buttons
• 88 combinations of materials and hardness scales (calibrations)
• Photofixing of tested objects
• Extended temperature range (freezing down to – 40°C)
• Internal memory and PC communication
• New, intuitive menu with push-button tips
• Optional wireless mini-printer
• Waterproof housing
• Rubber protected bumper.
