HEAVY-DUTY HYDRAULIC SWING BEAM SHEARS - MCD B Series

B SERIES SWING BEAM HYDRAULIC GUILLOTINE SHEARS

Increased productivity with double speed concept.50% more cuts/minute with half of the original cutting capacity. Shears cutting thickness from 6 mm – up to 25 mm, cutting length from 2 meter – up to 6 meter. Provides high cutting quality with low cutting angle design machine concepts. Unique construction feature has a fixed angle of cut.

Standard Features

• ELGO P40T Touch screen NC Control Unit
• Rexroth / Hoerbiger hydraulic system
• Manual blade gap adjustment system
• mm NC Controlled, Programmable, motorized back gauge
• Double Speed cutting machine concept
• 250 mm throat depth
• Programmable back gauge retract feature
• Back gauge swing-up feature for sheets longer than 1.000 mm
• Stroke adjustment on the control panel for increasing stroke number for short cutting efficiency
• Transfer table with roller balls
• Upper blade 2 edges / Bottom blade 4 edges
• Unique components that reduce maintenance need.
• Front support arms 1.000 mm, with ruler scale, T channel & flip stops
• Front and side protective covers
• Illumination cutting line
• Emergency stop buttons
• Front finger protection guard, 1.000 mm which has swing-up feature
• Foot pedal
• Special designed covers with movable controller arm
• Emergency stop buttons

Optional Features

• Pneumatic Sheet support system (Type 1)
• Pneumatic Sheet support system- with Return to sender feature (Type 2)
• CNC controlled Auto blade gap adjustment system
• Angular gauge 0-180º
• Longer front sheet supports & squaring arm
• Special throat depth 500 mm
• Full length opening front finger guard
• Laser guard for front finger protection
• Special alloy blades
• Laser cutting line
• Oil cooler and oil heater
• AC cooling unit electrical cabinet
• Automatic or Manual central lubrication
• CNC controlled front sheet feeder arms
• Rear laser barrier with CE conformity
• Machine without special design covers
