      Hydraulic Press Brake MVD - D Series

      D SERIES

      Top of the class, advanced CNC controllers and equipped to handle most complex jobs. 410 mm Stoke and 510 mm throat depth can do a lot more than other.

      Standard Features

      • Y1, Y2, X, R CNC 4 Axes (X + R Servo)
      • 410 mm Stroke, 510 mm Throat Depth
      • ESA S650 CNC Control Unit
      • ±0,03 accuracy SERVO motorized back gauge. X=750 mm, R=250 mm
      • Quick clamp Promecam punch tool holder
      • Sliding front sheet support arms with hand Wheel
      • Motorized Anti-deflection crowning with original Wila wedges
      • MVD special narrow bottom table (European type)
      • GIVI optic linear scales
      • Standard punch tools (H: 67, 85°, R:08)
      • Standard die tools (60×60 mm, 4 Vee V=16-22-35-50 mm, 85°, H:60)
      • LED illumination on RAM

      Optional Features

      • X + R to 4-6-8 axis back gauge options
      • Rolleri Rol200 hydraulic punch clamping
      • Wila hydraulic punch clamping
      • Wide bottom table for Multi Vee dies
      • mm X axis travel
      • AKAS or DSP front laser safety systems
      • Additional back gauge fingers
      • Front laser safety

      Download the brochure

      Description

      D SERIES

      Top of the class, advanced CNC controllers and equipped to handle most complex jobs. 410 mm Stoke and 510 mm throat depth can do a lot more than other.

      Standard Features

      • Y1, Y2, X, R CNC 4 Axes (X + R Servo)
      • 410 mm Stroke, 510 mm Throat Depth
      • ESA S650 CNC Control Unit
      • ±0,03 accuracy SERVO motorized back gauge. X=750 mm, R=250 mm
      • Quick clamp Promecam punch tool holder
      • Sliding front sheet support arms with hand Wheel
      • Motorized Anti-deflection crowning with original Wila wedges
      • MVD special narrow bottom table (European type)
      • GIVI optic linear scales
      • Standard punch tools (H: 67, 85°, R:08)
      • Standard die tools (60×60 mm, 4 Vee V=16-22-35-50 mm, 85°, H:60)
      • LED illumination on RAM

      Optional Features

      • X + R to 4-6-8 axis back gauge options
      • Rolleri Rol200 hydraulic punch clamping
      • Wila hydraulic punch clamping
      • Wide bottom table for Multi Vee dies
      • mm X axis travel
      • AKAS or DSP front laser safety systems
      • Additional back gauge fingers
      • Front laser safety
