LK ULTRA Coordinate measuring machine
LK ULTRA Coordinate measuring machine
Made for very-large-scale measurement applications the LK Metrology Ultra CMM Series, with its elevated guideways design, offers among the best and most flexible solutions in the industry today for 3D dimensional inspection.
The Ultra range offers three machine design variants, the monolithic design with an integrated work-table, the classic gantry design, and the proven guideways on U-foundation design which can be implemented as above ground, ground level, or, in sub-ground foundation pit installations. All variants are based upon a common modular design concept providing high performance, reliability and an easy to maintain measuring system.
The Ultra range of solutions has a proven pedigree within aerospace airframe and large blades inspection, land transportation large engine and transmission components, large scale gears, power generation, large turbines, maritime engine and propellers, locomotive components and very-large-scale precision engineering.
The Ultra Series is available in standard, incremental sizes of 500mm, featuring X-axis up to 16 meters, the Y-axis from 4.5 meters to 6 meters and Z-axis up to 3 meter with larger strokes available upon request.
