From small to large sized workpiece, from general turning to C-axis machining. The Slant-bed lathe, HT series can be equipped with suitable options for high precision work. Two cutting lengths for selection: 750mm and 1250mm. 51mm bar capacity with powerful 15kW (30 min. rate) high power spindle motor, max. torque 392 Nm (18.5 kW with torque output 605 Nm is available on request).
Features
Bar capacity: 51 mm
Cartridge design of headstock allows easy spindle replacement.
C axis with braking system enables the machine to perform milling, drilling, tapping and boring functions.
Hydraulic turret provides fast turret index, non-stop and bi-directional and high accuracy performance.
From small to large sized workpiece, from general turning to C-axis machining. The Slant-bed lathe, HT series can be equipped with suitable options for high precision work. Two cutting lengths for selection: 750mm and 1250mm. 51mm bar capacity with powerful 15kW (30 min. rate) high power spindle motor, max. torque 392 Nm (18.5 kW with torque output 605 Nm is available on request).
Features
Bar capacity: 51 mm
Cartridge design of headstock allows easy spindle replacement.
C axis with braking system enables the machine to perform milling, drilling, tapping and boring functions.
Hydraulic turret provides fast turret index, non-stop and bi-directional and high accuracy performance.
Financing solutions for the purchase of new equipment, through BCR Leasing or Grenke.
See Financing MethodsSwing over bed | 600 mm |
---|---|
Max. cutting dia. (with turret) | 580 mm |
Max. cutting length (with turret) | 750/1250 mm |
X axis travel | 305 mm |
Z axis travel | 750/1250 mm |
Slant bed degree | 45° |
Spindle speed | 4500 rpm |
Bar capacity | 51(A2-6) mm |
Chuck size | 200(8″) mm/inch |
Spindle main power | Fagor:12/18.5 kw Fanuc:11/15 kw Siemens:17/22.5 kw |
Rapid feed (X&Z) | 24 / 24 m/min |
Machine weight | 5400 kg |
Warranty 12 or 24 months
