Nikon ModelMaker H120 laser scanner

Ultra-fast high-definition 3D scanning

The cutting-edge ModelMaker H120 firmly pushes the ever-exacting boundaries of handheld laser scanning. Incorporating blue laser technology, ultra-fast frame rate, specially developed Nikon optics and the ability to measure the most challenging parts this represents the next generation of portable laser scanning. The H120 makes no compromises in addressing the market needs by efficiently delivering the most detailed and accurate data in a fraction of the time of competing technologies – no matter the size or the material.

Key benefits

• Extremely low noise data thanks to Nikon lens and blue laser technology
• Scanner accuracy of 7 microns
• Able to measure the most precise details on parts of any size
• Measures at over 450 stripes every second on all materials
• Full Field-of-View indicator for precise scanning
• Real-time optimization of the laser for every single measured point
• Designed for use under all shop floor or field conditions

Uncompromising performance

The ModelMaker H120 guarantees fast data collection over a large area with no compromise on small details – offering great flexibility in a single solution even when cycle time is critical, no matter the type of parts measured.

By combining a frame rate of 450 Hz, a stripe width up to 120 mm and non-interpolated point spacing of 35 μm, users benefit from high productivity and detailed measurements optimised within a single sensor.

The MCAx S arm further enhances the user experience by adding the ability to scan truly cable free, through high-speed Wi-Fi connectivity and battery power with absolutely no reduction in speed, quality or data coverage.

The superior accuracy of the ModelMaker H120 sensor ensures it stands far apart from similarly perceived technology, further pushing the traditionally accepted boundaries of handheld laser scanners.

Measure the most challenging materials

Patented Enhanced Sensor Performance (ESP4) provides automatic real-time adjustment of the laser intensity for every single point in the same image frame.

• Ensures full data regardless of the laser line spanning materials of completely different optical properties.
• Measure high contrast reflectivity changes, highly absorptive coatings, near-mirrored finishes and near-transparent materials.
• No reduction in data rate, even when scanning wirelessly.

Low noise data and very fine details

Expertly crafted bespoke in-house lens design enables the smallest structural resolution and lowest noise measurements in handheld scanning.

The specially developed Nikon optics and hand-assembled low-speckle blue laser source technology provide incredible details such as surface texture, very sharp edges and even dust, scratches and abrasions.

Nikon does not use interpolation techniques to increase data rates. Every point is an optically measured point.
