      Video-endoscope IT Concepts iRis X PRO

      iRis X PRO – Flexible videoscope system

      Extremely compact dimensions, minimal weight and optimal handling are the outstanding attributes of the iRis PRO Videoscope System by IT Concepts.

      Inspections in remote or inaccessible areas of the harsh industrial environments now are feasible in no time and with an undreamed easiness. Only little efforts and iRis PRO is ready for use within seconds. You can move the distal end to any desired position fast, easy and precisely, thanks to the approved tactile 4-way articulation of up to 180°. The high brightness of the LED light source guarantee, that you don’t miss any detail on the 7” high resolution TFT display. The integrated, changeable and rechargeable high power batteries assure 2 hours of operating time. The balanced handle – designed for real – handed operation – allows long and effortless working. With diameters of 4.0 mm and 6.0 mm and lengths from 1.5 m to 7.5 m the iRis X PRO leaves nothing to be desired.

      The iRis X PRO Inspection System is a “ready-to-go” Video Kit which includes the iRis PRO Inspection System specified by articulation, diameter and working length of the following list and all necessary basic accessories, as one battery), Charger, and Neck-Holder. It comes in iRis Case (up to 5 m length, IATA Standard) or iRis Caseplus (from 6 m length, non IATA).



      Operating unit

      Display size:7.0″
      Display resolution:1280 x 800 Pixel
      Operating system:EIOS (Endoscopic Imaging Operation System)
      User interface:USB
      Power supply, primary:Rechargeable Li-ion battery
      Power supply, secondary:12 V adapter (optional accesorys)
      Documentation
      Video format:MPEG4 (.avi)
      Image format:BMP (.bmp), JPEG (.jpg), PNG (.png)
      Storage:intern 16GB / USB (16GB in delivery)
      Measurement
      Method:Comparative Measurement

      Camera control

      Sensor:High resolution Super HAD CCD image sensor
      Illumination
      Type:High-power LED with faseroptic / High-power LED on the TIP (only 6mm X PRO)
      Illumination control:3 steps
      Operating environment
      Tip operating temperature:140° C less than 5 Minutes/ -25° C to +80° C
      System operating temperature:-25° C to +46° C
      Storage temperature:-25° C to +60° C
      Relative humidity:95% less than – non condensing
      Waterproof:Probe and distal End up to 1 bar – 10.2m H2O
      Resistance:Probe and distal End to oils and saline (5%)

      Download the brochure

      Description

      iRis X PRO – Flexible videoscope system

      Extremely compact dimensions, minimal weight and optimal handling are the outstanding attributes of the iRis PRO Videoscope System by IT Concepts.

      Inspections in remote or inaccessible areas of the harsh industrial environments now are feasible in no time and with an undreamed easiness. Only little efforts and iRis PRO is ready for use within seconds. You can move the distal end to any desired position fast, easy and precisely, thanks to the approved tactile 4-way articulation of up to 180°. The high brightness of the LED light source guarantee, that you don’t miss any detail on the 7” high resolution TFT display. The integrated, changeable and rechargeable high power batteries assure 2 hours of operating time. The balanced handle – designed for real – handed operation – allows long and effortless working. With diameters of 4.0 mm and 6.0 mm and lengths from 1.5 m to 7.5 m the iRis X PRO leaves nothing to be desired.

      The iRis X PRO Inspection System is a “ready-to-go” Video Kit which includes the iRis PRO Inspection System specified by articulation, diameter and working length of the following list and all necessary basic accessories, as one battery), Charger, and Neck-Holder. It comes in iRis Case (up to 5 m length, IATA Standard) or iRis Caseplus (from 6 m length, non IATA).



      Operating unit

      Display size:7.0″
      Display resolution:1280 x 800 Pixel
      Operating system:EIOS (Endoscopic Imaging Operation System)
      User interface:USB
      Power supply, primary:Rechargeable Li-ion battery
      Power supply, secondary:12 V adapter (optional accesorys)
      Documentation
      Video format:MPEG4 (.avi)
      Image format:BMP (.bmp), JPEG (.jpg), PNG (.png)
      Storage:intern 16GB / USB (16GB in delivery)
      Measurement
      Method:Comparative Measurement

      Camera control

      Sensor:High resolution Super HAD CCD image sensor
      Illumination
      Type:High-power LED with faseroptic / High-power LED on the TIP (only 6mm X PRO)
      Illumination control:3 steps
      Operating environment
      Tip operating temperature:140° C less than 5 Minutes/ -25° C to +80° C
      System operating temperature:-25° C to +46° C
      Storage temperature:-25° C to +60° C
      Relative humidity:95% less than – non condensing
      Waterproof:Probe and distal End up to 1 bar – 10.2m H2O
      Resistance:Probe and distal End to oils and saline (5%)
      View more See less

      Do you have more questions?

      You can request an offer

      Video-endoscope IT Concepts iRis X PRO

      Request offer

      Funding

      Financing solutions for the purchase of new equipment, through BCR Leasing or Grenke.

      See Financing Methods

      Specifications

      Display size

      7.0″

      Display resolution

      1024 x 600 Pixel

      Operating system

      EIOS (Endoscopic Imaging Operating System)

      Diameter

      4.0 – 6.0 mm

      Working length

      1.5 – 7.5 m
