iRis X PRO – Flexible videoscope system
Extremely compact dimensions, minimal weight and optimal handling are the outstanding attributes of the iRis PRO Videoscope System by IT Concepts.
Inspections in remote or inaccessible areas of the harsh industrial environments now are feasible in no time and with an undreamed easiness. Only little efforts and iRis PRO is ready for use within seconds. You can move the distal end to any desired position fast, easy and precisely, thanks to the approved tactile 4-way articulation of up to 180°. The high brightness of the LED light source guarantee, that you don’t miss any detail on the 7” high resolution TFT display. The integrated, changeable and rechargeable high power batteries assure 2 hours of operating time. The balanced handle – designed for real – handed operation – allows long and effortless working. With diameters of 4.0 mm and 6.0 mm and lengths from 1.5 m to 7.5 m the iRis X PRO leaves nothing to be desired.
The iRis X PRO Inspection System is a “ready-to-go” Video Kit which includes the iRis PRO Inspection System specified by articulation, diameter and working length of the following list and all necessary basic accessories, as one battery), Charger, and Neck-Holder. It comes in iRis Case (up to 5 m length, IATA Standard) or iRis Caseplus (from 6 m length, non IATA).
Operating unit
| Display size: | 7.0″ | |
| Display resolution: | 1280 x 800 Pixel | |
| Operating system: | EIOS (Endoscopic Imaging Operation System) | |
| User interface: | USB | |
| Power supply, primary: | Rechargeable Li-ion battery | |
| Power supply, secondary: | 12 V adapter (optional accesorys) |
| Video format: | MPEG4 (.avi) | |
| Image format: | BMP (.bmp), JPEG (.jpg), PNG (.png) | |
| Storage: | intern 16GB / USB (16GB in delivery) |
| Method: | Comparative Measurement |
Camera control
| Sensor: | High resolution Super HAD CCD image sensor |
| Type: | High-power LED with faseroptic / High-power LED on the TIP (only 6mm X PRO) | |
| Illumination control: | 3 steps |
2.4 | 3.0 | 4.0 | 6.0 | |||||
| Diameter: | 2.4 mm | 3.0 mm | 4.0 mm | 6.0 mm | ||||
| Working length: | 1.0 – 3.0 m | 1.0 – 1.5 m | 1.0 – 3.0 m | 1.0 – 7.5 m | ||||
| Articulation: | 2-way | 2-way | 4-way | 4-way | ||||
| Integrated objective lens: | X | X | X | X | ||||
| Side view tip adapter: | – | – | – | X | ||||
| Side view option: | X | X | X | X |
| Tip operating temperature: | 140° C less than 5 Minutes/ -25° C to +80° C | |
| System operating temperature: | -25° C to +46° C | |
| Storage temperature: | -25° C to +60° C | |
| Relative humidity: | 95% less than – non condensing | |
| Waterproof: | Probe and distal End up to 1 bar – 10.2m H2O | |
| Resistance: | Probe and distal End to oils and saline (5%) |
