      5-Axis Vertical Machining Center – AXILE G6 APC

      G6 APC integrates 2-pallet or 6-pallet changer to increase autonomy and flexibility. Workpiece loading and unloading are done while machining, reducing downtime and enlarging working time per day. The machine is prepared to integrate multi-pallet systems in case longer autonomy is required.

      Features

      6-pallet pool for APC6.

      Loading / unloading station at the back.

      G6 APC table with gate open / gate close

      Description

      G6 APC integrates 2-pallet or 6-pallet changer to increase autonomy and flexibility. Workpiece loading and unloading are done while machining, reducing downtime and enlarging working time per day. The machine is prepared to integrate multi-pallet systems in case longer autonomy is required.

      Features

      6-pallet pool for APC6.

      Loading / unloading station at the back.

      G6 APC table with gate open / gate close

      View more See less

      Do you have more questions?

      You can request an offer

      5-Axis Vertical Machining Center – AXILE G6 APC

      Request offer

      Funding

      Financing solutions for the purchase of new equipment, through BCR Leasing or Grenke.

      See Financing Methods

      Specifications

      Table & Workpiece

      Table size: 500 x 500 mm

      Table loading: 400 kg

      Travel

      X/Y/Z axis: 650/850/500 mm

      Feed rate X/Y/Z: 36 m/min

      V axis: 2110 mm

      Feed rate V: 25.8 m/min

      Rotary Axes

      A swivelling: +/- 120 deg

      C rotary: 360 deg

      A max speed: 100 rpm

      C max speed: 200 rpm



      Spindle

      Spindle speed: 20000 rpm (standard) / 15000 rpm (optional)

      Motor Output: 25/40 kW (standard) / 30/46 kW (optional)

      Accuracy

      Positioning accuracy: 0.005 mm

      Repeatability: ±0.0025 mm

      Guarantee

      Warranty 12 or 24 months
