      Benchtop Scanning Electron Microscope Neoscope SEM JCM 7000

      Benchtop Scanning Electron Microscope Neoscope SEM JCM 7000

      The SEM 7000 Electron Microscope – has advanced automated functions, along with benchtop automation and software allow easy imaging of elemental analysis samples for all users of all experience levels.

      It provides real-time 3D imaging because it is equipped with a high-resolution digital camera and secondary and retrospective electron detectors (SED and BSED) and is considered a SMART-FLEXIBLE-STRONG device.

      Strengths

      SMART – The latest innovations are incorporated into the bench platform to make SEM accessible to all. All controls are at the user’s fingertips through an intuitive software interface. Automatic condition setting is based on sample type and application for imaging in minutes. Seamless navigation from media chart or optical image (optional) to high-resolution SEM image enhances productivity.

      FLEXIBLE – Choose the right platform. Add options such as step navigation system (color camera), motorized tilt-rotate stand for sample handling, fully embedded EDS for elemental analysis, and Smile View Map for 3D image reconstruction and surface texture analysis.

      POWERFUL – High-resolution tungsten (W) filament source enables magnification up to 100,000X. Large analytical camera can handle samples up to 80 mm (D) x 50 mm (H). Secondary and backscatter electron detectors, along with high and low vacuum modes of operation, allow a wide variety of sample types to be studied.

       Technical specifications Neoscope SEM 7000

      • Zoom: 10x – 100.000x
      • Display zoom: 24x – 202.168 x
      • Observation mode: High vacuum/ Low vacuum
      • Accelerating voltage: 5KV, 10KV, 15KV
      • Electron source: Tungsten filament / Wehnelt
      • XY travel (motorized): x=40 mm, y= 40 mm
      • Maximum part dimensions: 80mm (D) x 50mm (H)
      • SEM 7000 unit dimensions: 324 mm (W) x 586 mm (D) x 566 mm (H)
      • SEM unit weight: 67 kg
      • Document format: BMP, TIFF, JPEG, PNG
      • Computer: Desktop PC, Windows 10
      • Monitor: 24 inch.

      Download the brochure

      Description

      Benchtop Scanning Electron Microscope Neoscope SEM JCM 7000

      The SEM 7000 Electron Microscope – has advanced automated functions, along with benchtop automation and software allow easy imaging of elemental analysis samples for all users of all experience levels.

      It provides real-time 3D imaging because it is equipped with a high-resolution digital camera and secondary and retrospective electron detectors (SED and BSED) and is considered a SMART-FLEXIBLE-STRONG device.

      Strengths

      SMART – The latest innovations are incorporated into the bench platform to make SEM accessible to all. All controls are at the user’s fingertips through an intuitive software interface. Automatic condition setting is based on sample type and application for imaging in minutes. Seamless navigation from media chart or optical image (optional) to high-resolution SEM image enhances productivity.

      FLEXIBLE – Choose the right platform. Add options such as step navigation system (color camera), motorized tilt-rotate stand for sample handling, fully embedded EDS for elemental analysis, and Smile View Map for 3D image reconstruction and surface texture analysis.

      POWERFUL – High-resolution tungsten (W) filament source enables magnification up to 100,000X. Large analytical camera can handle samples up to 80 mm (D) x 50 mm (H). Secondary and backscatter electron detectors, along with high and low vacuum modes of operation, allow a wide variety of sample types to be studied.

       Technical specifications Neoscope SEM 7000

      • Zoom: 10x – 100.000x
      • Display zoom: 24x – 202.168 x
      • Observation mode: High vacuum/ Low vacuum
      • Accelerating voltage: 5KV, 10KV, 15KV
      • Electron source: Tungsten filament / Wehnelt
      • XY travel (motorized): x=40 mm, y= 40 mm
      • Maximum part dimensions: 80mm (D) x 50mm (H)
      • SEM 7000 unit dimensions: 324 mm (W) x 586 mm (D) x 566 mm (H)
      • SEM unit weight: 67 kg
      • Document format: BMP, TIFF, JPEG, PNG
      • Computer: Desktop PC, Windows 10
      • Monitor: 24 inch.

      View more See less

      Do you have more questions?

      You can request an offer

      Benchtop Scanning Electron Microscope Neoscope SEM JCM 7000

      Request offer

      Funding

      Financing solutions for the purchase of new equipment, through BCR Leasing or Grenke.

      See Financing Methods

      Specifications

      Specifications

      Direct magnification: x10 to 100,00

      Display magnification: x24 to 202,168

      Mode: High-Vacuum/Low Vacuum mode

      Accelerating voltage: 5 kV, 10 kV, 15 kV (3 stages)

      Electron source: Tungsten filament / Wehnelt Integrated gird

      Specimen stage: X-Y motor drive stage, X: 40 mm Y: 40 mm

      Maximum specimen size: 80 mm diameter x 50 mm height

      File format: BMP, TIFF, JPEG, PNG

      Computer: Desktop PC Windows® 10

      Monitor: 24 inch

      Main unit dimensions: (W) 324 mm x (D) 586 mm x (H) 566 mm

      Main unit weight: 67 kg.
