Industrial Computed Tomography E1 Configurable X-ray / CT inspection system
DESCRIPTION
E1 CONFIGURABLE X-RAY/ CT INSPECTION SYSTEM SINGLE SOURCE 6-AXIS
The M1 system is an economical, large-envelope modular inspection system. The perimeter frame and cantilevered sample stage allows for free and clear access around the sample stage for ease of sample setup.
Supporting sources up to 450 kV offers the necessary power to penetrate through high-density parts and generate scatter-free CT volumes with micron accuracy. The system is available with flat-panel detector technology and Nikon micro focus sources.
FEATURES
- Large inspection envelope
- Install into existing radiation enclosure or supplied with new modular radiation enclosure
- Patented X-ray tube technology. 225 kV, 320 kV and 450 kV available
- Large format 16-bit detector technology and image processing tools
- Intuitive software interface
- Advanced 3D visualization and analysis
- Customizable macros to automate work flow
APPLICATIONS
- Evaluation of precision parts and large castings, complex mechanisms and internal components;
- Part-to-CAD comparison;
- Reverse engineering;
- Detailed failure analysis;
- Advanced material research and analysis of biological structures;
- Digital archiving of models;
- Troubleshooting of assembly issues.
