      Optical measuring system Metrios Cross and Metrios Cross HD

      Optical measuring system Metrios Cross and Metrios Cross HD

      Metrios is an optical device for bi-dimensional control, which allows operators to perform tests in the process fair and objective quality control.

      Metrios is specially designed to work directly in the production hall during final inspection before shipment. The equipment is easy to use, just place the piece to be inspected on the mass of the system, press a button and the machine automatically detects the profile piece.

      The benefits of Metrios

      Measurement parts directly in the production hall means that operators can analyze the tracks near the center of its takeover, and can intervene immediately in the production process to maintain the desired tolerances.

      With Metrios can analyze the entire batch of parts, which reduces the measurement time and increase productivity.

      Equipment structure

      Metrios engineers chose the materials and construction techniques specifically to a system that can be used directly in the production hall, with no need for a metrology laboratory. The equipment is made of alloy steel to withstand rugged use in harsh environments the production halls. Dimensional calculations combined with the analysis of deformation and the three temperature sensors allow the structure to remain stable Metrios, providing accurate results regardless of where it is used.



      Lighting in the lower – ensure maximum precision and repeatability

      Illuminator integrated coaxial bishop – is ideal for illuminating surfaces uniform, making it possible to measure every detail, such as blind holes, writings or markings.



      Software

      The software is 100% developed by programmers meters and is divided in two macro areas (production and programming) to combine ease of use with maximum versatility.



      Description

      Optical measuring system Metrios Cross and Metrios Cross HD

      Metrios is an optical device for bi-dimensional control, which allows operators to perform tests in the process fair and objective quality control.

      Metrios is specially designed to work directly in the production hall during final inspection before shipment. The equipment is easy to use, just place the piece to be inspected on the mass of the system, press a button and the machine automatically detects the profile piece.

      The benefits of Metrios

      Measurement parts directly in the production hall means that operators can analyze the tracks near the center of its takeover, and can intervene immediately in the production process to maintain the desired tolerances.

      With Metrios can analyze the entire batch of parts, which reduces the measurement time and increase productivity.

      Equipment structure

      Metrios engineers chose the materials and construction techniques specifically to a system that can be used directly in the production hall, with no need for a metrology laboratory. The equipment is made of alloy steel to withstand rugged use in harsh environments the production halls. Dimensional calculations combined with the analysis of deformation and the three temperature sensors allow the structure to remain stable Metrios, providing accurate results regardless of where it is used.



      Lighting in the lower – ensure maximum precision and repeatability

      Illuminator integrated coaxial bishop – is ideal for illuminating surfaces uniform, making it possible to measure every detail, such as blind holes, writings or markings.



      Software

      The software is 100% developed by programmers meters and is divided in two macro areas (production and programming) to combine ease of use with maximum versatility.



      View more See less

      Do you have more questions?

      You can request an offer

      Optical measuring system Metrios Cross and Metrios Cross HD

      Request offer

      Funding

      Financing solutions for the purchase of new equipment, through BCR Leasing or Grenke.

      See Financing Methods

      Specifications

      Metrios Cross with Sliding Stage

      Field of view – 265 x 200 mm high resolution for small and medium components

      Accuracy – (5+0.01L [mm]) [µm]

      Repeatability – (2+0.01L [mm]) [µm]

      Piece size on Z axis – 100 mm

      Metrios Cross HD with Sliding Stage

      Field of view – 70 x 70 mm highest resolution of the range

      Accuracy – (2,5+0.01L [mm]) [µm]

      Repeatability – (1,5+0.01L [mm]) [µm]

      Piece size on Z axis – 100 mm

      Applications

      Here you can see some examples for Metrios applications:

      Applications for 2D measuring system – Metrios

      View more

      Guarantee

      Warranty 12 or 24 months
