      MICROCUT TURNING MACHINE SERIES 76HT/HTL

      From small to large sized workpiece and from general turning to C-axis machining. The slant-bed lathe, HT series can be equipped with suitable options for high precision work. Two cutting lengths for selection: 750 mm and 1250 mm. 76 mm bar capacity with powerful 18.5 kW (30 min. rate) high power spindle motor, max. torque 907 Nm (22 kW with torque output 1,078 Nm on request).

      Features

      – Bar capacity: 76mm

      – Cartridge design of headstock allows easy spindle replacement.

      – C axis with braking system enables the machine to perform milling, drilling, tapping and boring functions.

      – Hydraulic turret provides fast turret index, non-stop and bi-directional and high accuracy performance.

      Description

      From small to large sized workpiece and from general turning to C-axis machining. The slant-bed lathe, HT series can be equipped with suitable options for high precision work. Two cutting lengths for selection: 750 mm and 1250 mm. 76 mm bar capacity with powerful 18.5 kW (30 min. rate) high power spindle motor, max. torque 907 Nm (22 kW with torque output 1,078 Nm on request).

      Features

      – Bar capacity: 76mm

      – Cartridge design of headstock allows easy spindle replacement.

      – C axis with braking system enables the machine to perform milling, drilling, tapping and boring functions.

      – Hydraulic turret provides fast turret index, non-stop and bi-directional and high accuracy performance.

      View more See less

      Do you have more questions?

      You can request an offer

      MICROCUT TURNING MACHINE SERIES 76HT/HTL

      Request offer

      Funding

      Financing solutions for the purchase of new equipment, through BCR Leasing or Grenke.

      See Financing Methods

      Specifications

      Swing over bed

      600 mm

      Max. cutting dia. (with turret)

      580 mm

      Max. cutting length (with turret)

      750 / 1250 mm

      X axis travel

      305 mm

      Z axis travel

      750 / 1250 mm

      Slant bed degree

      45°

      Spindle speed

      3000 rpm

      Bar capacity

      76(A2-8) mm

      Chuck size

      250(10″) mm(inch)

      Spindle main power

      Fagor:17/25 kw
      Fanuc:15/18.5 kw
      Siemens:30/45 kw

      Rapid feed (X&Z)

      24 / 24 m/min

      Machine weight

      5500/6500 kg

      Guarantee

      Warranty 12 or 24 months
