      ilz Self Reversing Tapping Attachment GNCK High performance tapping attachments with integrated reversing gear

      Application

      Application: tapping, roll forming
      Machine type: machining centres and special purpose machines

      Features

      • self reversing gear
      • direct collet location
      • damping elements between drive key in the spindle and the coupling sleeve
      • balls used in the couplings elements
      • hydrostatic pressure compensation for IC version
      • constant tapping speed (through built- in reversing gear)
      • exchangeable drivers BN17…
      • built-in length adjustment screw
      • sealed, stable version of the stop arm

      Advantages

      • reversing of machine spindle not required – shortest processing time possible, minimum time saving 200 – 400 ms per thread, substantially less electrical power consumption
      • high concentricity – better life time of the tool, reduced wear, less unbalanced mass
      • avoiding premature wear – less maintenance intensive
      • exact disengaging point –  exact thread depth, high repeat accuracy
      • no axial movement of the spindle into tension, even when the coolant flow is blocked – no risk of collision through extended tool
      • ideal cutting conditions – longer tool life time
      • positive torque transmission of the tap and of the driver in the spindle – no twisting or slipping of the tap in the collet
      • taps can be set to the required length – no input data error of tool length in machine offset (no risk of collision)
      • no malfunction due to contamination or through too much gap in the stop arm – reduced down time of the machine, prevention of collision / no damage from displaced stop arm
